Hybrid Stepper Motor Driver Controller CNC Single Axis TB6600 2/4 Phase

รายละเอียดสินค้า : 20KHZ Single Axis TB6600 2/4 Phase Hybrid Stepper Motor Driver

บอร์ด Driver stepper motor ขับกระแสได้สูงสุด 4A  หมุนด้วยความละเอียดสูงสุด 32 Microstep

Features:
1. 100% brand new and high quality.
2. Bipolar constant current chopper
3. High-speed optocoupler signal isolation input
4. Electrical input signal is TTL compatible
5. Stationary current is automatically reduced by half
6. Suitable for any small-and-medium automatic equipment with CNC controller, such as X-Y-Z tables, labeling machines, laser cutters, engraving machines, and pick-place devices.

Specifications:
1. Supply Voltage: 9~42VDC
2. Input voltage: DC 12 ~ 48V
3. Operating Temperature: -10 to 45 ˚C
4. Storage temperature: -40 to 70 ˚C
5. Max Drive Current: 4A
6. Chopping Frequency: 20KHZ
